1200 Series Early Riser Planters 6 – 24 rows
1200 Series Early Riser Planters 6 – 24 rows
The 1200 Series Early Riser® Planters sets the industry benchmark for consistency in row spacing and plant population accuracy. Engineered to deliver uniformity, the Early Riser Planters allow for versatility in rugged conditions and produce higher yields on average.
Maximize Yield Potential
The 1200 Series Early Riser Planters ensures excellent seed-to-soil contact and uniformity with consistent depth control and accuracy across the planter. Side-by-side trials show Early Riser Planters produce 6% more plants on average above the competition.
Hot Line
111-0000-1111
Product Introduction
Row Spacing
6- or 8-row, 30-in, 36-in, 38-in or 40-in spacing
Frame Size
7×7
Sections
1
Seed Drives
1 mechanical
Specifications
| Seed Hopper | Row Hoppers |
|---|---|
| Hookup To Tractor | Mounted |
| Row Spacings – in (mm) | 30, 36, 38, 40 (762, 914, 965, 1016) |
|---|
| Standard Row-Unit Hopper Capacity bu (US) | 1.9 |
|---|
| Metering Device – Option 1 | Vacuum |
|---|---|
| Furrow-forming Device | 14″ staggered discs, 10.5 degree Vee |
| Seed Delivery, Meter To Furrow | Gravity drop tube |
| Depth Gauging System | Single handle, infinite settings |
| Closing System | Inverted discs and press wheel |
| Standard Down Force Method | Spring |
| Standard Seed Drive | Chain drive, mechanical tranmission |
|---|
| Residue Tine Wheels, Row Cleaners | Non-Float tine wheels available |
|---|
| Monitor – Option 1 | Early Riser IV |
|---|
| Number Of Frame Sections | 1 |
|---|---|
| Frame Type | Rigid |
| Min Power Needed hp | 100 |
|---|---|
| Drawbar/Hitch Requirement | Three-point quick hitch, Category 3 or 3N |
